Product Advantages
-
Flexible Adaptation
One Rack One Management: Each battery rack is adapted to one string PCS.
Based on this architecture, it can adapt to different PCS and refine battery management.
-
Advanced Protection
Triple‑layer fire protection and seven‑level electrical safeguards.
Features automatic disconnector protection and a 2h+ fire‑resistant enclosure.
-
Enhanced Efficiency
AI Thermal Management: Reduces system energy consumption by 40%. DC RTE ≥96%, AC RTE ≥88.5%. Operational noise≤74dB.
Product Parameters
Swipe Left
| Rated Capacity | 5015.96kWh |
| Cell Type | LFP 3.2V / 314Ah |
| System Configuration | ((1P104S)4S)12P |
| Operating Voltage | 1040V DC~1497.6V DC |
| Nominal DC Voltage | 1331.2V DC |
| Charge‑Discharge Rate | 0.5P |
| Relative Humidity | 0~95%RH |
| Pack IP Rating | IP67 |
| Enclosure IP Rating | IP55 |
| Anti‑corrosion Class | ≥C4 |
| Altitude | 4000m (>3000m Derating) |
| Ambient Temperature | -30℃~55℃ (>45℃ Derating) |
| Thermal Management | Liquid Cooling / Heating |
