Product Advantages
-
For Extreme‑Condition
Applications IP54 protection rating, delivering excellent water‑proof, dust‑proof, salt‑mist‑proof and anti‑corrosion performance.
-
Long‑Term
Safety & Reliability CE certified to European standards; supports seamless dual‑mode switching between off‑grid and grid‑tied operation.
-
Easy‑to‑Use & High‑Efficiency
Operation Supports parallel operation of up to 11 units; CD displays core parameters in real time.
-
Smart Connected
Management & Control Built‑in Wi‑Fi function; real‑time viewing of power generation output and grid‑feeding status.
Product Parameters
Swipe Left
| General Parameter | |
| Operating temperature range | -10℃ ~ +50℃ (derating above 45℃ @ rated output power) |
| Humidity | 20% ~ 95% |
| Operating altitude | ≤ 4000 m, derating above 2000m |
| Audible noise | ＜ 55 dB (A) @ 1 m |
| Communication | |
| Interface | RS485, Bluetooth, WiFi, 4G (optional) |
| Mechanical | |
| Cooling | Intelligent Air Cooling |
| Installation type | Wall‑mounting |
| Ingress Protection | IP 21 |
