Product Advantages
-
Superior Integration
High‑capacity 587 Ah battery cells increase system energy density by 30% and reduce land occupancy by 20%.
Lightweight design keeps total container weight below standard limits, enabling easier transportation and installation.
-
Comprehensive Safety
Triple‑layer fire protection and seven‑level electrical safeguards.
Intelligent thermal management maintains cell temperature difference within ≤3℃.
AI‑based intelligent monitoring provides full system coverage and ensures reliable real‑time operation.
-
Improved Flexibility
Optimized system efficiency reduces energy consumption by 40%, with DC RTE ≥95%.
Horizontal‑mounted liquid cooling unit effectively reduces operating noise to ≤80 dB.
Product Parameters
Swipe Left
| Rated Capacity | 6251.31kWh |
| Cell Type | LFP 3.2V / 587Ah |
| System Configuration | ((1P104S)4S)8P |
| Operating Voltage | 1040V DC~1497.6V DC |
| Nominal DC Voltage | 1331.2V DC |
| Charge‑Discharge Rate | 0.5P |
| Relative Humidity | 0~95%RH |
| Pack IP Rating | IP67 |
| Container IP Rating | IP55 |
| Anti‑corrosion Class | ≥C4 |
| Altitude | ≤3000m |
| Ambient Temperature | ‑30℃~55℃ (>45℃ Derating) |
