Product Advantages
-
Outstanding Performance
4000‑cycle long‑life rating; efficient charge‑discharge operation over a wide temperature range of ‑20℃ ~ 50℃.
-
Easy Installation
All‑in‑one fast installation; supports parallel expansion of up to 10 units for flexible capacity‑upgrade requirements.
-
Safe and Reliable
Dual‑protection solution with multi‑level physical isolation and intelligent BMS, providing full‑lifecycle electrical protection.
-
User‑Friendly
Supports high‑output‑power operation; industry‑leading 10‑year warranty commitment.
Product Parameters
Swipe Left
| Nominal Capacity (Ah) | 100 |
| Nominal Voltage (Vdc) | 51.2 |
| Nominal Energy (kWh) | 5.12 |
| Usable Energy (kWh)* | 4.61 |
| Depth of Discharge (%)* | 90 |
| Dimensions (mm) | 406(W)*590(D)*140(H) |
| Weight (kg) | 50 |
| Working Voltage (Vdc) | 44.8 ~ 58.4 |
| Discharge Cut‑off Voltage (Vdc) | 43.2 |
| Standard Charge/Discharge Current (A) | 50 |
